5 Things to Determine the Correct Garage Door Spring Size

4 min read
5 Things for correct spring size blog card

We have Lots of Options for Angle, Struts and Track!

SSC offers numerous options for angle, struts,
shaft and track in a variety of sizes and gauge thicknesses
to ensure you have what you need to get the job done.

Additional Resources: Be sure to check out our blog How to Measure and Order Torsion Springs.

Don’t have our Spring Engineering App Yet?  You can download them HERE for Apple, Android, PC & Mac.

Standard Lift

Most residential garage doors use standard lift doors where there is approximately 12” of headroom for doors that use torsion springs and at least 8.5” of clearance for extension spring type of counterbalance.


Hi-lift garage doors are used when there is a need for increased space below the open door. Garages that have high ceilings for things such as a car lift would be a good use for a hi-lift door.

Vertical Lift

Vertical lift doors are more common in a commercial setting where there are large buildings with high ceilings that don’t make it ideal to support horizontal tracks. The required ceiling height will need to be at least the height of the door. Many dock doors in industrial settings are configured with hi-lift.

2. Drum Type & Part Number

Drums are stamped with part number 98% of time. If none is present the drum will need to be measured and compared to existing drums with the same dimension. Drum sizes are standard in the garage door industry no matter the manufacturer 99% of the time.

Measuring The Garage Door Drum

If the part number is unknown or unable to be read, you can measure the drum and use the SSC App to find a similar drum. To determine the drum sized used there are two measurements you will need to complete. The circumference of the flat part and the outside diameter of the drum.

Garage Door Drum Measurement Diagram

Standard Lift Drums

Standard lift drums are designed to have a consistent cable wrap across the width of the drum to allow for the lift of the garage door.

Hi-Lift Drums

Hi-lift drums have a raised portion and a flat portion like a standard lift drum. The raised portion helps the garage door open faster to cover the longer or Hi-Lift portion of the door travel.

Vertical Lift Drums

Vertical drums are a tapered drum whose wraps of the cables gets smaller as the door travels. These drums allow for the door to be lifted vertically without weigh transfer into horizontal tracks.

3. Door Weight

The weight of the door is a critical piece of information to have and to be accurate. SSC has a video that walks through the process to weight a garage door. You can watch that video at the link below.

4. Track Radius

There are a two standard garage door radius of 12” and 15” you will find on most residential homes. Measuring the track of a garage door is a simple process that requires a level and tape measure.

How to Measure the Track Radius

How to calculate the track radius. Hold a level at the bottom of the track junction (where the vertical track and curved portion of the track connect). Next take a tape measure and measure the distance from the center of the horizontal track to the top of the level. The measurement you get is what the radius of the door is.

Diagram for how to measure garage door track radius

5. Door Height

Measure the door with a tape measure form the top of the garage door to the bottom and round to the nearest 3” door height.

The garage door technician will need to properly identify all variables and use the SSC app to calculate whether they have the right spring for the garage door.
